Liteline Strip, Wrap Fixtures Standardize Lighting Without Slowing Crews

Liteline’s STRIP and WRAP Series fixtures are built for unpredictable jobsite conditions and tight timelines. Both families use field‑selectable wattage and CCT to reduce SKU overload, simplify ordering and give installers the flexibility to fine‑tune output onsite. STRIP’s narrow, open-profile linear design delivers high output, while WRAP is a compact lensed linear fixture that diffuses light for a cleaner, softer result. Both are available in surface, wall, suspended and continuous-row mounting.

For crews working across warehouses, stairwells, stockrooms, parking garages and utility corridors, these fixtures deliver consistent performance without slowing down the schedule.

The STRIP Series covers a wide range of applications with lumen packages from 2,200 to 12,000 lumens and lengths from 2 to 8 feet. Tandem alignment tabs and included hardware support surface, wall, pendant and continuous‑run mounting. Pinch‑locking clips allow quick access to the 120‑347V constant‑current driver, and optional occupancy sensing and emergency backup expand the fixture’s utility for energy‑sensitive or code‑driven spaces.

The WRAP Series offers a compact, application‑ready solution for stairwells, parking garages and light industrial environments. With selectable wattages from 29 to 40 watts and lumen outputs from 3,800 to 5,200 lumens, the fixtures provide uniform illumination in a familiar wraparound form factor. Tool‑free lens removal speeds driver access, and optional occupancy sensing and emergency backup support retrofit and new‑build requirements.

For facility managers, both families reduce long‑term maintenance and help standardize lighting across multiple spaces. For contractors, they deliver predictable performance, faster installs and fewer callbacks.

Technical Specifications of Liteline STRIP Series:

• Surface, wall or pendant
• Approved for damp or indoor locations
• 2 ft, 4 ft and 8 ft lengths available
• Wattage (selectable): 17/19/22W; 28/33/40W; 55/66/80W
• 2,250-12,000 lm
• CCT selectable: 3000K / 3500K / 4000K
• Dimming: 0–10V
• Voltage: 120–347V
• cETLus certified

Technical Specifications of Liteline WRAP Series:

• Surface or wall, 4 ft length
• Approved for damp or indoor locations
• Wattage (selectable): 29/33/40W
• 3800/4300/5200 lm
• CCT selectable: 3000K / 3500K / 4000K
• Dimming: 0-10V
• Voltage: 120-347V
• Certification: UL Certified – Safety US CA

Learn more about Liteline’s STRIP and WRAP fixtures at https://www.liteline.com/
